Bevel gear slurry valve

Slurry Valve Series

Z573X bevel gear slurry valve has compact design, small space occupation, light weight, easy installation, perfect wear-resistant and anti-blocking measures, easy maintenance and long service life. Widely used in fly ash treatment, bulk material conveying, chemical plants, food and beverage, papermaking, pulp industry, industrial sewage, urban sewage treatment industries. Main performance specification of Z573X bevel gear slurry valve

Hotline:

0577-67962833 / 13567723322

Inquiry Contact

Product Details

Z573X Bevel Gear Slurry Valve Z573X Slurry Valve Bevel Gear Transmission Slurry Valve Bevel Gear Slurry Valve Executive Standard:

Design and manufacture: JB/T8691-1998

Structure length: GB/T15188.2-94

Flange connection: GB/T9113.1-2000 JB/T79-94

Test and acceptance: GB/T13927-92

Z573X bevel gear slurry valve performance parameters:

Nominal pressure PN

Shell test 1.5 Mpa

Sealing test 1.1 Mpa

Working temperature Rubber≤80℃ Teflon seal≤180℃ Hard seal≤425℃

Applicable media Syrup, pulp, sewage, coal slurry, ash, slag-water mixture

Z573X bevel gear slurry valve parts material:

Body, cover Carbon steel, stainless steel

valve plate stainless steel

Stem Stainless Steel

Nominal pressurePN	Seal test	shell test	Operating temperature	Applicable media
0.6MPa	0.66MPa	0.9MPa	-10℃～120℃	Mud, cinder, paper pulp, grain pulp, granular materials and other media
1.0MPa	1.1MPa	1.5MPa	-10℃～120℃

Main appearance and connection dimensions of Z573X bevel gear single-clamp knife gate valve(mm)

Nominal diameter DN	Structure lengthL		D1	D2	H	L0	D0	n-M
Nominal diameter DN	0.6	1.0.	D1	D2	H	L0	D0	n-M
50	48	48	100	125	300	400	250	4-M16
65	48	48	120	145	310	400	250	4-M16
80	50	50	135	160	330	400	250	4-M16
100	50	50	155	180	380	400	250	8-M16
125	50	50	185	210	440	400	250	8-M16
150	60	60	210	240	500	400	250	8-M20
200	60	60	265	295	580	400	250	8-M20
250	70	70	320	350	670	420	300	12-M20
300	70	80	368	400	820	420	300	12-M20
350	80	90	428	460	900	420	300	16-M20
400	90	120	482	515	1020	420	300	16-M22
450	90	120	532	565	1150	420	300	20-M22
500	90	130	585	620	1250	420	300	20-M22
600	140	140	685	725	1500	420	300	20-M27
700	140	140	800	840	1750	420	300	24-M27
800	190	190	905	950	2000	420	300	24-M30
900	203	203	1005	1050	2300	420	300	28-M30
1000	216	216	1115	1160	2500	420	300	28-M30
1200	254	254	1325	1380	2800	420	300	32-M36
